מד עובי מתכת + גשש 1.65-25.40 מ”מ לנחושת אלומיניום, פלדה, נירוסטה, ברזל יצוק, פרספקס, PVC, פוליסטירן ופוליאוריתן

Name: מד עובי מתכת + גשש 1.65-25.40 מ"מ לנחושת אלומיניום, פלדה, נירוסטה, ברזל יצוק, פרספקס, PVC, פוליסטירן ופוליאוריתן
Brand: Elcometer
SKU: 100277
Availability: PreOrder

₪10,990.00

Interface Echo (IE); The total thickness from the top of any coating through to the material density boundary (typically the back-wall) is measured. Suitable for measurement of materials between 1.65mm and 25.4mm (0.065” to 1”) thick.

Echo Echo (EE); ideal for measuring thin materials, the material thickness from the top surface of the material to the material density boundary (typically the backwall) is measured. Suitable for measurement of materials between 0.15mm and 10.15mm (0.006” to 0.4”) thick.

Plastic Mode (PLAS); specifically used for measuring very thin plastics between 0.15mm and 5mm (0.006” to 0.197”) thick. A graphite delay line is required when using this mode.

שלח הודעת ווטסאפ

ניתן להזמנה מראש

הדפסה

דמי משלוח:	₪39.00
זמן אספקה:	עד 45 ימי עסקים
יצרן:	Elcometer
דגם:	PTG6-TXC
ברקוד:	006039700001
אחריות:	אחריות לשנה
מספר מכירה:	100277

When precision is key, the PTG6 has a measurement range of 0.15mm (0.006”) to 25.40mm (1.000”) with ±1% accuracy, across three measurement modes, Interface Echo (I-E), Echo-Echo (E-E), and Plastic Mode (PLAS). This gauge allows users to take measurements with pinpoint accuracy.

Calibration Options

The PTG6 has a number of calibration options. Using an uncoated sample of test material of a known thickness, the gauge can be calibrated using 1-Point calibration. Alternatively, the user can select one of 39 pre-set materials stored within the gauge including; aluminium, steel, stainless steel, cast iron, plexiglass, PVC, polystyrene and polyurethane.

The PTG6 also offers the additional calibration options of 2-Point & Velocity.

Data Output

Compatible with ElcoMaster® software, individual readings can be downloaded via USB to PC or similar device for further analysis.

PTG6 Precision Thickness Gauge

Features:

Interface Echo (I-E) Echo-Echo (E-E) ) & Plastic Mode (PLAS) measurement modes
Measurement range from 0.15mm (0.006″) to 25.40mm (1.00″)
2-Point, 1-Point, Material, Thickness Set and Factory Calibration options
User selectable measurement rate; 4,8,16 readings per second
User selectable reading resolution; 0.1mm (0.01″) or 0.01mm (0.001″)
USB output to ElcoMaster®

Preview Html DETAILED DESCRIPTIONWhen precision is key, the PTG6 has a measurement range of 0.15mm (0.006”) to 25.40mm (1.000”) with ±1% accuracy, across three measurement modes, Interface Echo (I-E), Echo-Echo (E-E), and Plastic Mode (PLAS). This gauge allows users to take measurements with pinpoint accuracy.
